inverter 30A MPPT Solar Charge

With battery constant current, charging, floating charging control.

With temperature compensation function, according to the use of the battery and equipment, appropriate adjustment of the working conditions, the reduction or compensation function.

It has the functions of overvoltage, overload, overdischarge and overcharge.

It has the functions of solar panel reverse connection, battery reverse connection, output short circuit and internal short circuit protection.

Has the event record function, records the user needs each kind of information.

Friendly interface, easy to operate.

     MPPT - Maximum Power Tracking Solar Controller. Multiply the voltage U and the current I of the solar cell to obtain the power P, and then judge whether the output power of the solar cell reaches the maximum at this time. If it is not running at the maximum power point, adjust the pulse width, modulate the output duty cycle D, change the charging current, and perform real-time sampling again to determine whether to change the duty cycle. This optimization process ensures that the solar cells always operate at the maximum power point to fully utilize the output energy of the solar cell array.

    To realize the full potential of the MPPT solar controller, the array voltage should be much higher than the battery voltage. MPPT solar conditioners are the preferred solution for higher power systems (lowest overall system cost due to smaller cable cross-section). MPPT solar conditioners will also get more energy when the solar cell temperature is low (below 45°C) or very high (above 75°C) or the irradiance is very low.
